Attribute
Description
Manufacturer Part Number
FX135A-327
Manufacturer
Description
TUNING FORK,
32.768 kHz,
12.5PF,
SMD,
FU; TUNING FORK,...
Note :
GST will not be applied to orders shipping outside of India
Stock: 3000
Distributor: 145
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 280 | ₹ 97.09 | ₹ 27,185.20 |
| 210 | ₹ 108.30 | ₹ 22,743.00 |
| 160 | ₹ 112.02 | ₹ 17,923.20 |
| 120 | ₹ 115.76 | ₹ 13,891.20 |
| 75 | ₹ 119.50 | ₹ 8,962.50 |
| 35 | ₹ 145.63 | ₹ 5,097.05 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Oscillation Rate Hz | 32.768kHz | |
| Oscillator Drift Tolerance | - | |
| Hz Deviation Limit | ±20ppm | |
| Output Load Cap Value | 12.5pF | |
| ESR Value | 70 kOhm | |
| Op Temp Range | -40°C ~ 85°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2-SMD | |
| Package Size Specs | 0.126" L x 0.059" W (3.20mm x 1.50mm) | |
| Vertical Dimension | 0.035" (0.90mm) |
Description
Presents the measured equivalent series resistance at 70 kOhm. Operates at a frequency of 32.768kHz. Upholds ±20ppm frequency tolerance for precise electronic functionality. Records a height of 0.035" (0.90mm) for precise dimensional accuracy. Load capacitance 12.5pF to ensure stable electrical operation. Mounting style Surface Mount for structural integrity. Operating temperature range -40°C ~ 85°C for environmental resilience. Enclosure/case 2-SMD providing mechanical and thermal shielding. Dimensions 0.126" L x 0.059" W (3.20mm x 1.50mm) for mechanical or electrical components. Dimension measurement 0.126" L x 0.059" W (3.20mm x 1.50mm) for component details. Peak Vce(on) at Vge 0.035" (0.90mm) for transistor parameters.
