Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Oscillation Rate Hz | 32.768kHz | |
| Oscillator Drift Tolerance | - | |
| Hz Deviation Limit | ±20ppm | |
| Output Load Cap Value | 12.5pF | |
| ESR Value | 50 kOhm | |
| Op Temp Range | -40°C ~ 85°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 4-SOJ, 5.50mm pitch | |
| Package Size Specs | 0.343" L x 0.146" W (8.70mm x 3.70mm) | |
| Vertical Dimension | 0.098" (2.50mm) |
Description
Presents the measured equivalent series resistance at 50 kOhm. Operates at a frequency of 32.768kHz. Upholds ±20ppm frequency tolerance for precise electronic functionality. Records a height of 0.098" (2.50mm) for precise dimensional accuracy. Load capacitance 12.5pF to ensure stable electrical operation. Mounting style Surface Mount for structural integrity. Operating temperature range -40°C ~ 85°C for environmental resilience. Enclosure/case 4-SOJ, 5.50mm pitch providing mechanical and thermal shielding. Dimensions 0.343" L x 0.146" W (8.70mm x 3.70mm) for mechanical or electrical components. Dimension measurement 0.343" L x 0.146" W (8.70mm x 3.70mm) for component details. Peak Vce(on) at Vge 0.098" (2.50mm) for transistor parameters.
