APTGL240TL120G
Data Sheet
Attribute
Description
Manufacturer Part Number
APTGL240TL120G
Manufacturer
Description
POWER MOD IGBT4 3LVL INVERT SP6
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | Trench and Field Stop | |
| Max Collector-Emitter Breakdown | 1200V | |
| Maximum Collector Amps | 305A | |
| Maximum Power Handling | 1000W | |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 200A | |
| Entry Signal Category | 12.3nF @ 25V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | SP6 |
Description
Provides a maximum collector current (Ic) of 305A. Features a DC current gain hFE at Ic evaluated at 2.2V @ 15V, 200A. Designed as Trench and Field Stop IGBT type for effective power switching. Set up with 12.3nF @ 25V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case SP6 providing mechanical and thermal shielding. Peak power 1000W for device protection. Peak Vce(on) at Vge 2.2V @ 15V, 200A for transistor parameters. Highest collector-emitter breakdown voltage 1200V.
