APT25GLQ120JCU2
Data Sheet
Attribute
Description
Manufacturer Part Number
APT25GLQ120JCU2
Manufacturer
Description
PWR MOD IGBT4 1200V SOT227
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | Trench and Field Stop | |
| Max Collector-Emitter Breakdown | 1200V | |
| Maximum Collector Amps | 45A | |
| Maximum Power Handling | 170W | |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 25A | |
| Entry Signal Category | 1.43nF @ 25V | |
| Attachment Mounting Style | Chassis, Stud Mount | |
| Component Housing Style | SOT-227-4, miniBLOC |
Description
Provides a maximum collector current (Ic) of 45A. Features a DC current gain hFE at Ic evaluated at 2.4V @ 15V, 25A. Designed as Trench and Field Stop IGBT type for effective power switching. Set up with 1.43nF @ 25V input type for versatile applications. Mounting style Chassis, Stud Mount for structural integrity. Enclosure/case SOT-227-4, miniBLOC providing mechanical and thermal shielding. Peak power 170W for device protection. Peak Vce(on) at Vge 2.4V @ 15V, 25A for transistor parameters. Highest collector-emitter breakdown voltage 1200V.
