Stock: 390000
Distributor: 145
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 7110 | ₹ 3.76 | ₹ 26,733.60 |
| 5320 | ₹ 4.18 | ₹ 22,237.60 |
| 4110 | ₹ 4.33 | ₹ 17,796.30 |
| 2985 | ₹ 4.48 | ₹ 13,372.80 |
| 1930 | ₹ 4.62 | ₹ 8,916.60 |
| 795 | ₹ 5.62 | ₹ 4,467.90 |
Stock: 59
Distributor: 108
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 40.05 | ₹ 40.05 |
| 10 | ₹ 28.30 | ₹ 283.00 |
| 100 | ₹ 17.62 | ₹ 1,762.00 |
| 500 | ₹ 12.19 | ₹ 6,095.00 |
| 1000 | ₹ 10.50 | ₹ 10,500.00 |
| 3000 | ₹ 8.81 | ₹ 26,430.00 |
| 6000 | ₹ 7.83 | ₹ 46,980.00 |
| 9000 | ₹ 7.21 | ₹ 64,890.00 |
| 24000 | ₹ 6.32 | ₹ 1,51,680.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Field Effect Transistor Type | MOSFET P-Channel, Metal Oxide | |
| Drain-Source Breakdown Volts | 30V | |
| Continuous Drain Current at 25C | 2A (Ta) | |
| Max On-State Resistance | 80 mOhm @ 2A, 10V | |
| Max Threshold Gate Voltage | 1V @ 11µA | |
| Gate Charge at Vgs | 5nC @ 10V | |
| Input Cap at Vds | 500pF @ 15V | |
| Maximum Power Handling | 500mW | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | TO-236-3, SC-59, SOT-23-3 |
Description
Measures resistance at forward current MOSFET P-Channel, Metal Oxide for LED or diode evaluation. Supports a continuous drain current (Id) of 2A (Ta) at 25°C. Supports Vdss drain-to-source voltage rated at 30V. Accommodates FET classification identified as MOSFET P-Channel, Metal Oxide. Upholds 5nC @ 10V gate charge at Vgs for reliable MOSFET functionality. The input capacitance is rated at 500pF @ 15V at Vds for optimal performance. Mounting style Surface Mount for structural integrity. Enclosure/case TO-236-3, SC-59, SOT-23-3 providing mechanical and thermal shielding. Peak power 500mW for device protection. Peak Rds(on) at Id 5nC @ 10V for MOSFET efficiency. Peak Rds(on) at Id and Vgs 80 mOhm @ 2A, 10V for MOSFET criteria. Peak Vgs(th) at Id 1V @ 11µA for MOSFET threshold level.
