ZVN4525E6TA
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Field Effect Transistor Type | MOSFET N-Channel, Metal Oxide | |
| Drain-Source Breakdown Volts | 250V | |
| Continuous Drain Current at 25C | 230mA (Ta) | |
| Max On-State Resistance | 8.5 Ohm @ 500mA, 10V | |
| Max Threshold Gate Voltage | 1.8V @ 1mA | |
| Gate Charge at Vgs | 3.65nC @ 10V | |
| Input Cap at Vds | 72pF @ 25V | |
| Maximum Power Handling | 1.1W | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | SOT-23-6 |
Description
Measures resistance at forward current MOSFET N-Channel, Metal Oxide for LED or diode evaluation. Supports a continuous drain current (Id) of 230mA (Ta) at 25°C. Supports Vdss drain-to-source voltage rated at 250V. Accommodates FET classification identified as MOSFET N-Channel, Metal Oxide. Upholds 3.65nC @ 10V gate charge at Vgs for reliable MOSFET functionality. The input capacitance is rated at 72pF @ 25V at Vds for optimal performance. Mounting style Surface Mount for structural integrity. Enclosure/case SOT-23-6 providing mechanical and thermal shielding. Peak power 1.1W for device protection. Peak Rds(on) at Id 3.65nC @ 10V for MOSFET efficiency. Peak Rds(on) at Id and Vgs 8.5 Ohm @ 500mA, 10V for MOSFET criteria. Peak Vgs(th) at Id 1.8V @ 1mA for MOSFET threshold level.
