Data Sheet
Attribute
Description
Manufacturer Part Number
MUJ-103A-500
Manufacturer
Description
Pulse Transformer,
Surface Mount
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Transformer Type | Isolation and Data Interface (Encapsulated) | |
| Inductance | 25mH | |
| Turns Ratio - Primary:Secondary | 1 : 1 : 2 : 2 | |
| E.T. | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 12.80mm L x 9.60mm W | |
| Height - Seated (Max) | 6.00mm |
