Attribute
Description
Manufacturer Part Number
JB15HAP-2B
Manufacturer
Description
Tactile switch
Manufacturer Lead Time
27 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 307.05 | ₹ 307.05 |
| 25 | ₹ 286.58 | ₹ 7,164.50 |
| 50 | ₹ 275.01 | ₹ 13,750.50 |
| 100 | ₹ 255.43 | ₹ 25,543.00 |
| 200 | ₹ 237.63 | ₹ 47,526.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.125A @ 24VDC | |
| Actuator Type | Square Button | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, from Pins | 14.70mm | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 10.00mm x 10.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 265gf | |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
