Data Sheet
Attribute
Description
Manufacturer Part Number
ZW50F91AW1-Z
Manufacturer
Description
MICRO SW PIN PLNGR SPDT 5A 125V
Manufacturer Lead Time
Not specified
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 596.30 | ₹ 596.30 |
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 638.13 | ₹ 638.13 |
| 10 | ₹ 589.18 | ₹ 5,891.80 |
| 25 | ₹ 589.18 | ₹ 14,729.50 |
| 50 | ₹ 589.18 | ₹ 29,459.00 |
| 100 | ₹ 547.35 | ₹ 54,735.00 |
| 250 | ₹ 547.35 | ₹ 1,36,837.50 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Wire Leads | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Operating Force, Torque | 203gf | |
| Release Force | 50gf | |
| Pretravel | 0.047" (1.2mm) | |
| Differential Travel | 0.008" (0.2mm) | |
| Overtravel | 0.025" (0.6mm) |
