WRG32F2FBBNN
Data Sheet
Attribute
Description
Manufacturer Part Number
WRG32F2FBBNN
Manufacturer
Description
SWITCH ROCKER DPST 16A 125V
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Electrical Pathway | DPST | |
| Switch Operation Mode | On-Off | |
| Rated Current | 16A (AC) | |
| AC Voltage Max | 125V | |
| DC Voltage Max | - | |
| Actuator Design | Concave (Curved) | |
| Activator Cap Shade | Black | |
| Activator Label Indicator | O - | |
| LED Illumination Shades | - | |
| Standard Illumination Volts | - | |
| Attachment Mounting Style | Panel Mount, Snap-In | |
| Lead Termination Type | Quick Connect - 0.250" (6.3mm) | |
| Dust Water Resistance Rating | - | |
| Mount Cutout Specs | Rectangular - 30.00mm x 22.00mm |
Description
Includes labels marked as O - for straightforward identification. Utilizes a Concave (Curved) actuator type tailored for application requirements. Set up to circuit type characterized as DPST. Crafted with actuator or cap color indicated as Black for visual distinction. Provides a current rating of 16A (AC). Mounting style Panel Mount, Snap-In for structural integrity. Cutout dimensions Rectangular - 30.00mm x 22.00mm for precise mounting. Operation mode switch On-Off for electrical function. Termination type Quick Connect - 0.250" (6.3mm) for connector or device. Peak Vce(on) at Vge DPST for transistor parameters. Maximum AC voltage rating 125V for device specifications.
