VX-56-1A3
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Electrical Pathway | SPDT | |
| Switch Operation Mode | On-Mom | |
| Rated Current | 5A (AC/DC) | |
| AC Voltage Max | 125V | |
| DC Voltage Max | 30V | |
| Activator Mechanism Type | Lever, Roller | |
| Attachment Mounting Style | Chassis Mount | |
| Lead Termination Type | Solder, Quick Connect - 0.187" (4.7mm) | |
| Dust Water Resistance Rating | IP40 | |
| Operating Force, Torque | 30gf | |
| Detachment Pressure | - | |
| Initial Travel Distance | 0.157" (4.0mm) | |
| Switch Travel Difference | 0.030" (0.8mm) | |
| Excess Travel Distance | 0.062" (1.6mm) |
Description
Fitted with a Lever, Roller actuator type to execute the intended function. Measures resistance at forward current 30gf for LED or diode evaluation. Set up to circuit type characterized as SPDT. Provides a current rating of 5A (AC/DC). Provides differential travel rated at 0.030" (0.8mm). Rated with IP IP40 for protection against dust and moisture ingress. Mounting style Chassis Mount for structural integrity. Excess travel 0.062" (1.6mm) for mechanical safety and longevity. Initial movement 0.157" (4.0mm) for switch or mechanical control. Operation mode switch On-Mom for electrical function. Termination type Solder, Quick Connect - 0.187" (4.7mm) for connector or device. Peak Vce(on) at Vge SPDT for transistor parameters. Maximum AC voltage rating 125V for device specifications. Maximum DC voltage rating 30V for components.
