HA55L-2223088LF
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Inductor Core Type | - | |
| Coil Inductance Value | 8.83µH | |
| Accuracy Tolerance Percentage | - | |
| Rated Current | 41A | |
| Saturation Current | 33A | |
| Electromagnetic Interference Protection | Shielded | |
| Direct Current Resistance | 2 mOhm Max | |
| Quality Factor at Frequency | - | |
| Self-Resonance Frequency | - | |
| Ambient Temp Range | -40°C ~ 155°C | |
| Test Frequency | 100kHz | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Non Standard | |
| Package Size Specs | 0.906" L x 0.867" W (23.00mm x 22.00mm) | |
| Maximum Mounted Height | 0.669" (17.00mm) |
Description
Measures resistance at forward current Shielded for LED or diode evaluation. Accommodates saturation current specified at 33A. Provides a current rating of 41A. Offers DC resistance recorded at 2 mOhm Max for precise circuit functionality. Accommodates 100kHz frequency during testing to ensure precise device validation. Maximum seated height of 0.669" (17.00mm) for components mounted on the board. Offers 8.83µH inductance for tuning and filtering circuits. Mounting style Through Hole for structural integrity. Operating temperature -40°C ~ 155°C for thermal stability. Enclosure/case Non Standard providing mechanical and thermal shielding. Shielding Shielded for EMI/RFI shielding. Dimensions 0.906" L x 0.867" W (23.00mm x 22.00mm) for mechanical or electrical components. Dimension measurement 0.906" L x 0.867" W (23.00mm x 22.00mm) for component details. Peak Vce(on) at Vge Shielded for transistor parameters.
