CM600DY-24S
Data Sheet
Attribute
Description
Manufacturer Part Number
CM600DY-24S
Manufacturer
Description
IGBTs - Arrays,
Modules,
1200V,
600A,
4050W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | - | |
| Max Collector-Emitter Breakdown | 1200V | |
| Maximum Collector Amps | 600A | |
| Maximum Power Handling | 4050W | |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 600A | |
| Entry Signal Category | 60nF @ 10V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module |
Description
Provides a maximum collector current (Ic) of 600A. Features a DC current gain hFE at Ic evaluated at 2.25V @ 15V, 600A. Set up with 60nF @ 10V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case Module providing mechanical and thermal shielding. Peak power 4050W for device protection. Peak Vce(on) at Vge 2.25V @ 15V, 600A for transistor parameters. Highest collector-emitter breakdown voltage 1200V.
