APTGF180H60G
Data Sheet
Attribute
Description
Manufacturer Part Number
APTGF180H60G
Manufacturer
Description
POWER MOD IGBT NPT FULL BRDG SP6
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | NPT | |
| Max Collector-Emitter Breakdown | 600V | |
| Maximum Collector Amps | 220A | |
| Maximum Power Handling | 833W | |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 180A | |
| Entry Signal Category | 8.6nF @ 25V | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | SP6 |
Description
Provides a maximum collector current (Ic) of 220A. Features a DC current gain hFE at Ic evaluated at 2.5V @ 15V, 180A. Designed as NPT IGBT type for effective power switching. Set up with 8.6nF @ 25V input type for versatile applications. Mounting style Chassis Mount for structural integrity. Enclosure/case SP6 providing mechanical and thermal shielding. Peak power 833W for device protection. Peak Vce(on) at Vge 2.5V @ 15V, 180A for transistor parameters. Highest collector-emitter breakdown voltage 600V.
