IXGH10N300
Data Sheet
Attribute
Description
Manufacturer Part Number
IXGH10N300
Manufacturer
Description
IGBTs - Single,
3000V,
18A,
100W
Manufacturer Lead Time
38 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | - | |
| Max Collector-Emitter Breakdown | 3000V | |
| Maximum Collector Amps | 18A | |
| Maximum Power Handling | 100W | |
| Vce(on) (Max) @ Vge, Ic | 5.2V @ 15V, 30A | |
| Entry Signal Category | Standard | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-247-3 |
Description
Provides a maximum collector current (Ic) of 18A. Features a DC current gain hFE at Ic evaluated at 5.2V @ 15V, 30A. Set up with Standard input type for versatile applications. Mounting style Through Hole for structural integrity. Enclosure/case TO-247-3 providing mechanical and thermal shielding. Peak power 100W for device protection. Peak Vce(on) at Vge 5.2V @ 15V, 30A for transistor parameters. Highest collector-emitter breakdown voltage 3000V.
