Attribute
Description
Manufacturer Part Number
FGD3040G2_F085
Manufacturer
Description
IGBTs - Single,
400V,
41A,
150W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Class | - | |
| Max Collector-Emitter Breakdown | 400V | |
| Maximum Collector Amps | 41A | |
| Maximum Power Handling | 150W | |
| Vce(on) (Max) @ Vge, Ic | 1.25V @ 4V, 6A | |
| Entry Signal Category | Logic | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | TO-252-3, DPak (2 Leads + Tab), SC-63 |
Description
Provides a maximum collector current (Ic) of 41A. Features a DC current gain hFE at Ic evaluated at 1.25V @ 4V, 6A. Set up with Logic input type for versatile applications. Mounting style Surface Mount for structural integrity. Enclosure/case TO-252-3, DPak (2 Leads + Tab), SC-63 providing mechanical and thermal shielding. Peak power 150W for device protection. Peak Vce(on) at Vge 1.25V @ 4V, 6A for transistor parameters. Highest collector-emitter breakdown voltage 400V.
