Attribute
Description
Manufacturer Part Number
MBR0520LT1G
Manufacturer
Description
SCHOTTKY RECTIFIER,
500mA,
20V,...
Manufacturer Lead Time
1 week
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 13
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 70 | ₹ 1.15000 | ₹ 80.50 |
Stock:
Distributor: 6
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3000 | ₹ 3.03000 | ₹ 9,090.00 |
| 18000 | ₹ 2.91000 | ₹ 52,380.00 |
Stock:
Distributor: 12
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 800 | ₹ 7.16000 | ₹ 5,728.00 |
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 27.39000 | ₹ 27.39 |
| 10 | ₹ 18.35000 | ₹ 183.50 |
| 100 | ₹ 7.64000 | ₹ 764.00 |
| 1000 | ₹ 5.27000 | ₹ 5,270.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 28.10000 | ₹ 28.10 |
Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 10 | ₹ 590.02000 | ₹ 5,900.20 |
| 50 | ₹ 367.88000 | ₹ 18,394.00 |
| 250 | ₹ 295.01000 | ₹ 73,752.50 |
| 1000 | ₹ 265.16000 | ₹ 2,65,160.00 |
| 3000 | ₹ 247.60000 | ₹ 7,42,800.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Schottky | |
| Reverse DC Voltage(Vr) | 20V | |
| Current - Average Rectified (Io) | 500mA | |
| Forward Voltage (Vf) | 385mV @ 500mA | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Reverse Leakage Current @ Vr | 250µA @ 20V | |
| Capacitance @ Vr, F | - | |
| Thermal Resistance | 150°C/W Jl | |
| Operating Temperature - Junction | -65°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SOD-123 |
