Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Signal Filtering Design | - | |
| Display Line Count | 2 | |
| Impedance at Hz | 360 Ohms @ 100 MHz | |
| Inductance at Specific Hz | - | |
| Peak Ampere Rating | 280mA | |
| Maximum DC Resistance | 450mOhm | |
| DC Voltage Max | 120V | |
| AC Voltage Max | - | |
| Ambient Temp Range | -40°C ~ 150°C | |
| Performance Rating Specs | - | |
| Certification Body | - | |
| Key Product Highlights | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Package Size Specs | 0.081" L x 0.049" W (2.05mm x 1.25mm) | |
| Upper Height Limit | 0.055" (1.40mm) | |
| Component Housing Style | Horizontal, 4 PC Pad |
Description
Offers a peak current rating of 280mA. Provides maximum DC resistance indicated at 450mOhm for design specifications. Ensures a maximum height of 0.055" (1.40mm) for adherence to design regulations. Retains 360 Ohms @ 100 MHz impedance at the operating frequency to ensure efficiency. Mounting style Surface Mount for structural integrity. Total lines 2 for wiring, displays, or communication. Operating temperature -40°C ~ 150°C for thermal stability. Enclosure Tape & Reel (TR) for component protection or transport. Enclosure/case Horizontal, 4 PC Pad providing mechanical and thermal shielding. Product condition Active for availability and lifecycle. Dimensions 0.081" L x 0.049" W (2.05mm x 1.25mm) for mechanical or electrical components. Dimension measurement 0.081" L x 0.049" W (2.05mm x 1.25mm) for component details. Maximum DC voltage rating 120V for components.
