TC75S63TU(TE85L,F)
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Signal Booster Category | CMOS | |
| Electrical Circuit Count | 1 | |
| Exit Signal Category | Voltage | |
| Voltage Slew Speed V/us | 1 V/?s | |
| Amplifier Bandwidth Gain | 3.5MHz | |
| 3dB Bandwidth | - | |
| Bias Input Amperage | 1pA | |
| Input Offset Voltage | 1mV | |
| Power Supply Amperage | 500?A | |
| Per-Channel Output Current | 4mA | |
| Single or Dual Supply Option | 2.2 V ~ 5.5 V | |
| Ambient Temp Range | -40?C ~ 85?C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-SMD (5 Leads), Flat Lead |
Description
Incorporates a CMOS amplifier design for improved signal transmission. Measures resistance at forward current 3.5MHz for LED or diode evaluation. Includes input bias current rated at 1pA. Presents per-channel output current rated at 4mA. Utilizes supply current defined as 500?A. Tuned with 3.5MHz gain bandwidth product for effective high-frequency performance. Mounting style Surface Mount for structural integrity. Total circuits 1 for electrical or electronic designs. Operating temperature -40?C ~ 85?C for thermal stability. Output type Voltage for system compatibility. Enclosure/case 6-SMD (5 Leads), Flat Lead providing mechanical and thermal shielding. Transition rate 1 V/?s for signal change speed. Peak Vce(on) at Vge 1 for transistor parameters. Input offset voltage 1mV for analog systems. Single/dual voltage supply ± 2.2 V ~ 5.5 V for various devices.
