TC75S54FU(TE85L,F)
Data Sheet
Attribute
Description
Manufacturer Part Number
TC75S54FU(TE85L,F)
Manufacturer
Description
Operational amplifier
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Signal Booster Category | General Purpose | |
| Electrical Circuit Count | 1 | |
| Exit Signal Category | - | |
| Voltage Slew Speed V/us | 0.7 V/?s | |
| Amplifier Bandwidth Gain | - | |
| 3dB Bandwidth | - | |
| Bias Input Amperage | 1pA | |
| Input Offset Voltage | 2mV | |
| Power Supply Amperage | 100?A | |
| Per-Channel Output Current | 700?A | |
| Single or Dual Supply Option | 3.5 V ~ 7 V, ?0.9 V ~ 1.8 V | |
| Ambient Temp Range | -40?C ~ 85?C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 6-TSSOP (5 Lead), SC-88A, SOT-353 |
Description
Incorporates a General Purpose amplifier design for improved signal transmission. Includes input bias current rated at 1pA. Presents per-channel output current rated at 700?A. Utilizes supply current defined as 100?A. Mounting style Surface Mount for structural integrity. Total circuits 1 for electrical or electronic designs. Operating temperature -40?C ~ 85?C for thermal stability. Enclosure/case 6-TSSOP (5 Lead), SC-88A, SOT-353 providing mechanical and thermal shielding. Transition rate 0.7 V/?s for signal change speed. Peak Vce(on) at Vge 1 for transistor parameters. Input offset voltage 2mV for analog systems. Single/dual voltage supply ± 3.5 V ~ 7 V, ?0.9 V ~ 1.8 V for various devices.
