TA75W01FUTE12LF
Data Sheet
Attribute
Description
Manufacturer Part Number
TA75W01FUTE12LF
Manufacturer
Description
Linear - Amplifiers - Instrumentation,
OP Amps,...
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Signal Booster Category | General Purpose | |
| Electrical Circuit Count | 2 | |
| Exit Signal Category | - | |
| Voltage Slew Speed V/us | - | |
| Amplifier Bandwidth Gain | - | |
| 3dB Bandwidth | - | |
| Bias Input Amperage | 45nA | |
| Input Offset Voltage | 2mV | |
| Power Supply Amperage | 700?A | |
| Per-Channel Output Current | 40mA | |
| Single or Dual Supply Option | 3 V ~ 12 V, ?1.5 V ~ 6 V | |
| Ambient Temp Range | -40?C ~ 85?C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 8-TSSOP, 8-MSOP (0.110", 2.80mm Width) |
Description
Incorporates a General Purpose amplifier design for improved signal transmission. Includes input bias current rated at 45nA. Presents per-channel output current rated at 40mA. Utilizes supply current defined as 700?A. Mounting style Surface Mount for structural integrity. Total circuits 2 for electrical or electronic designs. Operating temperature -40?C ~ 85?C for thermal stability. Enclosure/case 8-TSSOP, 8-MSOP (0.110", 2.80mm Width) providing mechanical and thermal shielding. Peak Vce(on) at Vge 2 for transistor parameters. Input offset voltage 2mV for analog systems. Single/dual voltage supply ± 3 V ~ 12 V, ?1.5 V ~ 6 V for various devices.
