Home Products High Quality Audio Components And Devices Amplifiers Analog Devices Inc ADD8704ACPZREEL7
Attribute
Description
Manufacturer Part Number
ADD8704ACPZ-REEL7
Manufacturer
Description
Linear - Amplifiers - Instrumentation,
OP Amps,...
Manufacturer Lead Time
12 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Signal Booster Category | - | |
| Electrical Circuit Count | 4 | |
| Exit Signal Category | - | |
| Voltage Slew Speed V/us | 6 V/?s | |
| Amplifier Bandwidth Gain | - | |
| 3dB Bandwidth | 6.8MHz | |
| Bias Input Amperage | - | |
| Input Offset Voltage | - | |
| Power Supply Amperage | 2.8mA | |
| Per-Channel Output Current | 35mA | |
| Single or Dual Supply Option | 4.5 V ~ 16 V | |
| Ambient Temp Range | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 16-VQFN Exposed Pad, CSP |
Description
Provides a -3dB bandwidth of 6.8MHz to ensure consistent signal quality. Presents per-channel output current rated at 35mA. Utilizes supply current defined as 2.8mA. Mounting style Surface Mount for structural integrity. Total circuits 4 for electrical or electronic designs. Enclosure/case 16-VQFN Exposed Pad, CSP providing mechanical and thermal shielding. Transition rate 6 V/?s for signal change speed. Peak Vce(on) at Vge 4 for transistor parameters. Single/dual voltage supply ± 4.5 V ~ 16 V for various devices.
