Data Sheet
Attribute
Description
Manufacturer Part Number
CM100DU-24NFH
Manufacturer
Description
IGBTs - Arrays,
Modules,
1200V,
100A,
560W
Manufacturer Lead Time
Not specified
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 8,178.21 | ₹ 8,178.21 |
| 10 | ₹ 7,667.35 | ₹ 76,673.50 |
| 100 | ₹ 6,900.17 | ₹ 6,90,017.00 |
| 250 | ₹ 6,644.74 | ₹ 16,61,185.00 |
| 500 | ₹ 6,542.39 | ₹ 32,71,195.00 |
| 1000 | ₹ 6,389.31 | ₹ 63,89,310.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Type | - | |
| Voltage - Collector Emitter Breakdown (Max) | 1200V | |
| Current - Collector (Ic) (Max) | 100A | |
| Power - Max | 560W | |
| Vce(on) (Max) @ Vge, Ic | 6.5V @ 15V, 100A | |
| Input Type | 16nF @ 10V | |
| Mounting Type | Chassis Mount | |
| Package / Case | Module |
