Attribute
Description
Manufacturer Part Number
1N3070TR
Manufacturer
Description
SMALL SIGNAL DIODE 200V 500mA DO-35; Dio; Diode Type:Small S...
Manufacturer Lead Time
Not specified
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 3
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1.87 | ₹ 1.87 |
| 10 | ₹ 1.87 | ₹ 18.70 |
| 100 | ₹ 1.87 | ₹ 187.00 |
| 1000 | ₹ 1.87 | ₹ 1,870.00 |
| 2500 | ₹ 1.69 | ₹ 4,225.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 14.24 | ₹ 14.24 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Standard | |
| Reverse DC Voltage(Vr) | 200V | |
| Current - Average Rectified (Io) | 500mA | |
| Forward Voltage (Vf) | 1V @ 100mA | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 50ns | |
| Reverse Leakage Current @ Vr | 100nA @ 175V | |
| Capacitance @ Vr, F | 5pF @ 0V, 1MHz | |
| Thermal Resistance | 300°C/W Ja | |
| Operating Temperature - Junction | 175°C (Max) | |
| Mounting Type | Through Hole | |
| Package / Case | DO-204AH, DO-35, Axial |
