Data Sheet
Attribute
Description
Manufacturer Part Number
BAS16-7-F
Manufacturer
Description
Diodes Rectifiers - Single,
75V,
200mA
Manufacturer Lead Time
28 weeks
Note :
GST will not be applied to orders shipping outside of India
Stock:
Distributor: 12
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3000 | ₹ 2.14 | ₹ 6,420.00 |
Stock:
Distributor: 2
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 10.68 | ₹ 10.68 |
Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 25 | ₹ 232.29 | ₹ 5,807.25 |
| 100 | ₹ 186.01 | ₹ 18,601.00 |
| 500 | ₹ 150.41 | ₹ 75,205.00 |
| 1000 | ₹ 134.39 | ₹ 1,34,390.00 |
| 3000 | ₹ 124.60 | ₹ 3,73,800.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Type | Standard | |
| Reverse DC Voltage(Vr) | 75V | |
| Current - Average Rectified (Io) | 200mA | |
| Forward Voltage (Vf) | 1.25V @ 150mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 4ns | |
| Reverse Leakage Current @ Vr | 1µA @ 75V | |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz | |
| Thermal Resistance | - | |
| Operating Temperature - Junction | -65°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
