Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B-2T | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Internal Structure Design | Bridge, Single Phase - SCRs/Diodes (Layout 1) | |
| Thyristor Diode Count | 2 SCRs, 2 Diodes | |
| Off-State Voltage Rating | 600 V | |
| Max Average On-State Current | - | |
| Max RMS On-State Current | - | |
| Max Gate Trigger Volts | 3 V | |
| Max Gate Trigger Amps | 80 mA | |
| Non-Repetitive Surge 50/60Hz | 600A @ 60Hz | |
| Maximum Holding Current | - | |
| Ambient Temp Range | -40°C ~ 125°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module |
Description
Provides a maximum gate trigger current (Igt) rated at 80 mA. Can handle surge current Itsm rated at 600A @ 60Hz for 50/60Hz. Mounting style Chassis Mount for structural integrity. Total SCRs/diodes 2 SCRs, 2 Diodes for circuit safeguarding. Operating temperature -40°C ~ 125°C (TJ) for thermal stability. Enclosure Bulk for component protection or transport. Enclosure/case Module providing mechanical and thermal shielding. Product condition Active for availability and lifecycle. Product or component classification series B-2T. Structure Bridge, Single Phase - SCRs/Diodes (Layout 1) for the design of components or materials. Highest gate trigger voltage 3 V for SCRs. Voltage 600 V in off-state for semiconductors or switches.
