Attribute
Description
Manufacturer Part Number
MA2S07700L
Manufacturer
Description
Diodes - RF,
Standard - Single,
35V,
100mA
Manufacturer Lead Time
27 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Semiconductor Diode Category | Standard - Single | |
| Max Peak Reverse Volts | 35V | |
| Maximum Amp Rating | 100mA | |
| Capacitance at Voltage and Frequency | 1.2pF @ 6V, 1MHz | |
| Resistance at Current Frequency | 850 mOhm @ 2mA, 100MHz | |
| Max Heat Dissipation | - | |
| Component Housing Style | SC-80 |
Description
Measures resistance at forward current 1.2pF @ 6V, 1MHz for LED or diode evaluation. Accommodates capacitance at Vr and frequency specified as 1.2pF @ 6V, 1MHz. Specifies maximum current capacity of 100mA. Includes diode type indicated as Standard - Single. Enclosure/case SC-80 providing mechanical and thermal shielding. Resistance at specified forward current and frequency 850 mOhm @ 2mA, 100MHz for accurate testing. Peak Vce(on) at Vge Standard - Single for transistor parameters. Maximum reverse voltage peak 35V for safeguarding.
