Attribute
Description
Manufacturer Part Number
PSMN050-80BS,118
Manufacturer
Description
MOSFET N-CH 80V 22A D2PAK
Manufacturer Lead Time
52 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Field Effect Transistor Type | MOSFET N-Channel, Metal Oxide | |
| Drain-Source Breakdown Volts | 80V | |
| Continuous Drain Current at 25C | 22A (Tmb) | |
| Max On-State Resistance | 46 mOhm @ 10A, 10V | |
| Max Threshold Gate Voltage | 4V @ 1mA | |
| Gate Charge at Vgs | 11nC @ 10V | |
| Input Cap at Vds | 633pF @ 12V | |
| Maximum Power Handling | 56W | |
| Attachment Mounting Style | - | |
| Component Housing Style | - |
Description
Measures resistance at forward current MOSFET N-Channel, Metal Oxide for LED or diode evaluation. Supports a continuous drain current (Id) of 22A (Tmb) at 25°C. Supports Vdss drain-to-source voltage rated at 80V. Accommodates FET classification identified as MOSFET N-Channel, Metal Oxide. Upholds 11nC @ 10V gate charge at Vgs for reliable MOSFET functionality. The input capacitance is rated at 633pF @ 12V at Vds for optimal performance. Peak power 56W for device protection. Peak Rds(on) at Id 11nC @ 10V for MOSFET efficiency. Peak Rds(on) at Id and Vgs 46 mOhm @ 10A, 10V for MOSFET criteria. Peak Vgs(th) at Id 4V @ 1mA for MOSFET threshold level.
