Attribute
Description
Manufacturer Part Number
BY228TR
Manufacturer
Description
Diodes Rectifiers - Single,
1500V (1.5kV),
3A
Manufacturer Lead Time
45 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Semiconductor Diode Category | Avalanche | |
| Reverse DC Voltage(Vr) | 1500V (1.5kV) | |
| Average DC Output Current | 3A | |
| Forward Voltage (Vf) | 1.5V @ 5A | |
| Operational Speed Rating | Standard Recovery >500ns, > 200mA (Io) | |
| trr Recovery | 20µs | |
| Reverse Leakage Current @ Vr | 5µA @ 1500V | |
| Capacitance at Voltage and Frequency | - | |
| Heat Dissipation Resistance | 70°C/W Ja | |
| Junction Temp Range | 140°C (Max) | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | SOD-64, Axial |
Description
Measures resistance at forward current 1.5V @ 5A for LED or diode evaluation. Delivers average rectified current (Io) recorded at 3A. Includes diode type indicated as Avalanche. Mounting style Through Hole for structural integrity. Resistance in the on-state 70°C/W Ja for efficient conduction. Junction operating temperature 140°C (Max) for component protection. Enclosure/case SOD-64, Axial providing mechanical and thermal shielding. Reverse recovery duration 20µs for switching diodes. Velocity Standard Recovery >500ns, > 200mA (Io) for mechanical or data efficiency. Thermal resistance value 70°C/W Ja for temperature regulation. Peak Vce(on) at Vge Avalanche for transistor parameters.
