Attribute
Description
Manufacturer Part Number
STPS10H100CFP
Manufacturer
Description
STPS10H100C Series 100 V 10 A Flange Mount Schottky Rectifie...
Note :
GST will not be applied to orders shipping outside of India
Stock: 3000
Distributor: 116
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100 | ₹ 19.61 | ₹ 1,961.00 |
| 50 | ₹ 19.96 | ₹ 998.00 |
| 30 | ₹ 20.32 | ₹ 609.60 |
| 10 | ₹ 20.67 | ₹ 206.70 |
| 1 | ₹ 22.18 | ₹ 22.18 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Diode Setup | 1 Pair Common Cathode | |
| Semiconductor Diode Category | Schottky | |
| Reverse DC Voltage(Vr) (Max) | 100V | |
| Average DC Output Current | 5A | |
| Forward Voltage (Vf) | 730mV @ 5A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | - | |
| Leakage at Vr | 3.5µA @ 100V | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-220-3 Full Pack |
Description
Measures resistance at forward current 730mV @ 5A for LED or diode evaluation. Delivers average rectified current (Io) recorded at 5A. Utilizes diode arrangement recognized as 1 Pair Common Cathode. Includes diode type indicated as Schottky. Mounting style Through Hole for structural integrity. Enclosure/case TO-220-3 Full Pack providing mechanical and thermal shielding. Reverse leakage current at Vr 3.5µA @ 100V for diode parameters. Velocity Fast Recovery =< 500ns, > 200mA (Io) for mechanical or data efficiency. Peak Vce(on) at Vge Schottky for transistor parameters.
