RF101L2STE25
Data Sheet
Attribute
Description
Manufacturer Part Number
RF101L2STE25
Manufacturer
Description
RF Series 1 A 200 V 25 ns Surface Mount Fast Recovery Diode ...
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Semiconductor Diode Category | Standard | |
| Reverse DC Voltage(Vr) | 200V | |
| Average DC Output Current | 1A | |
| Forward Voltage (Vf) | 870mV @ 1A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | 25ns | |
| Reverse Leakage Current @ Vr | 10µA @ 200V | |
| Capacitance at Voltage and Frequency | - | |
| Heat Dissipation Resistance | - | |
| Junction Temp Range | 150°C (Max) | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | DO-214AC, SMA |
Description
Measures resistance at forward current 870mV @ 1A for LED or diode evaluation. Delivers average rectified current (Io) recorded at 1A. Includes diode type indicated as Standard. Mounting style Surface Mount for structural integrity. Junction operating temperature 150°C (Max) for component protection. Enclosure/case DO-214AC, SMA providing mechanical and thermal shielding. Reverse recovery duration 25ns for switching diodes. Velocity Fast Recovery =< 500ns, > 200mA (Io) for mechanical or data efficiency. Peak Vce(on) at Vge Standard for transistor parameters.
