DL4937-13-F
Data Sheet
Attribute
Description
Manufacturer Part Number
DL4937-13-F
Manufacturer
Description
DL4937 Series 1 A 600 V Surface Mount Fast Recovery Rectifie...
Manufacturer Lead Time
28 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Semiconductor Diode Category | Standard | |
| Reverse DC Voltage(Vr) | 600V | |
| Average DC Output Current | 1A | |
| Forward Voltage (Vf) | 1.2V @ 1A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | 200ns | |
| Reverse Leakage Current @ Vr | 5µA @ 600V | |
| Capacitance at Voltage and Frequency | 15pF @ 4V, 1MHz | |
| Heat Dissipation Resistance | - | |
| Junction Temp Range | -65°C ~ 150°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | MELF (DL-41) |
Description
Measures resistance at forward current 1.2V @ 1A for LED or diode evaluation. Accommodates capacitance at Vr and frequency specified as 15pF @ 4V, 1MHz. Delivers average rectified current (Io) recorded at 1A. Includes diode type indicated as Standard. Mounting style Surface Mount for structural integrity. Junction operating temperature -65°C ~ 150°C for component protection. Enclosure/case MELF (DL-41) providing mechanical and thermal shielding. Reverse recovery duration 200ns for switching diodes. Velocity Fast Recovery =< 500ns, > 200mA (Io) for mechanical or data efficiency. Peak Vce(on) at Vge Standard for transistor parameters.
