SB540E-G
Data Sheet
Attribute
Description
Manufacturer Part Number
SB540E-G
Manufacturer
Description
Diodes Rectifiers - Single,
40V,
5A
Manufacturer Lead Time
15 weeks
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Semiconductor Diode Category | Schottky | |
| Reverse DC Voltage(Vr) | 40V | |
| Average DC Output Current | 5A | |
| Forward Voltage (Vf) | 550mV @ 5A | |
| Operational Speed Rating | Fast Recovery =< 500ns, > 200mA (Io) | |
| trr Recovery | - | |
| Reverse Leakage Current @ Vr | 500µA @ 40V | |
| Capacitance at Voltage and Frequency | 500pF @ 4V, 1MHz | |
| Heat Dissipation Resistance | 35°C/W Ja | |
| Junction Temp Range | -65°C ~ 125°C | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | DO-201AD, Axial |
