Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 6.5V | |
| Maximum Input Voltage | 32V | |
| First Rail Output Volts | 5V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Peak Output Current | 500mA | |
| Series Power Watts | 3W | |
| Isolation Barrier Voltage | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 3-SIP Module | |
| Package Size Specs | 0.46 L x 0.30 W x 0.40 H (11.6mm x 7.5mm x 10.2mm) | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 0.94 |
Description
Measures resistance at forward current Non-Isolated PoL Module for LED or diode evaluation. Delivers peak output current defined as 500mA. Offers efficiency evaluated at 0.94. Input voltage specified at 6.5V for secure operation. Mounting style Through Hole for structural integrity. Total outputs 1 for device interfacing. Operating temperature -40°C ~ 85°C for thermal stability. Output voltage 5V for electrical efficiency. Enclosure/case 3-SIP Module providing mechanical and thermal shielding. Series power from the manufacturer 3W for device selection. Dimensions 0.46 L x 0.30 W x 0.40 H (11.6mm x 7.5mm x 10.2mm) for mechanical or electrical components. Dimension measurement 0.46 L x 0.30 W x 0.40 H (11.6mm x 7.5mm x 10.2mm) for component details. Category Non-Isolated PoL Module for classification or specification. Peak Vce(on) at Vge Non-Isolated PoL Module for transistor parameters. Maximum input voltage 32V for protection. Minimum input voltage 6.5V for functionality. Voltage 5V for output 1 across various outputs.
