AFB0812SHD
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Variant | Tubeaxial | |
| DC Fan Bearing Mode | Ball | |
| Max Voltage Specification | 12VDC | |
| Ventilation Rate | 48.2 CFM (1.37m³/min) | |
| Airflow Static Pressure | 0.245 in H2O (61.0 Pa) | |
| Electrical Noise Level | 41 dB(A) | |
| Power Rating | 2.64W | |
| Revolutions Per Minute | 4000 RPM | |
| Ambient Temp Range | - | |
| Circuit End Method | 2 Wire Leads | |
| Package Size Specs | Square - 80mm L x 80mm H x 20mm W |
Description
Provides airflow rated at 48.2 CFM (1.37m³/min) for effective cooling. Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 0.245 in H2O (61.0 Pa). Designed with a DC fan bearing type indicated as Ball for optimal airflow. Includes a DC fan type rated at Tubeaxial for optimal cooling efficiency. Sound level 41 dB(A) for acoustic or electronic efficiency. Energy 2.64W for device power needs. RPM 4000 RPM for motors or mechanical systems. Dimensions Square - 80mm L x 80mm H x 20mm W for mechanical or electrical components. Dimension measurement Square - 80mm L x 80mm H x 20mm W for component details. Static pressure measurement 0.245 in H2O (61.0 Pa) for fluid or air systems. Termination method 2 Wire Leads for electrical or mechanical linkage. Peak Vce(on) at Vge 12VDC for transistor parameters. Voltage specification 12VDC for components.
