SMC5.7223K100J33TR12
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Storage Capacity Electrical | 0.022uF | |
| AC Voltage Max | 63V | |
| DC Voltage Max | 100V | |
| Insulating Dielectric Type | Polyphenylene Sulfide (PPS) | |
| Accuracy Tolerance Percentage | ±10% | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2220 (5750 Metric) | |
| Package Size Specs | 0.224" L x 0.197" W (5.70mm x 5.00mm) | |
| Maximum Mounted Height | 0.126" (3.20mm) | |
| Circuit End Method | Solder Pads | |
| Pin Lead Gap | - |
Description
Offers a capacitance level rated at 0.022uF to ensure circuit stability. Made with dielectric material identified as Polyphenylene Sulfide (PPS). Maximum seated height of 0.126" (3.20mm) for components mounted on the board. Mounting style Surface Mount for structural integrity. Operating temperature -55°C ~ 125°C for thermal stability. Enclosure/case 2220 (5750 Metric) providing mechanical and thermal shielding. Dimensions 0.224" L x 0.197" W (5.70mm x 5.00mm) for mechanical or electrical components. Dimension measurement 0.224" L x 0.197" W (5.70mm x 5.00mm) for component details. Termination method Solder Pads for electrical or mechanical linkage. Tolerance ±10% for precision in manufacturing. Peak Vce(on) at Vge 0.022uF for transistor parameters. Maximum AC voltage rating 63V for device specifications. Maximum DC voltage rating 100V for components.
