B32776G4506K
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Storage Capacity Electrical | 50uF | |
| AC Voltage Max | - | |
| DC Voltage Max | 450V | |
| Insulating Dielectric Type | Polypropylene (PP), Metallized | |
| Accuracy Tolerance Percentage | ±10% | |
| Series Resistance Equivalent | 4 mOhm | |
| Ambient Temp Range | -40°C ~ 105°C | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial | |
| Package Size Specs | 1.634" L x 1.102" W (41.50mm x 28.00mm) | |
| Maximum Mounted Height | 1.673" (42.50mm) | |
| Circuit End Method | PC Pins | |
| Pin Lead Gap | 1.476" (37.50mm) |
Description
Offers a capacitance level rated at 50uF to ensure circuit stability. Made with dielectric material identified as Polypropylene (PP), Metallized. Offers ESR rated at 4 mOhm. Maximum seated height of 1.673" (42.50mm) for components mounted on the board. Lead spacing 1.476" (37.50mm) for compliance with PCB design. Mounting style Through Hole for structural integrity. Operating temperature -40°C ~ 105°C for thermal stability. Enclosure/case Radial providing mechanical and thermal shielding. Dimensions 1.634" L x 1.102" W (41.50mm x 28.00mm) for mechanical or electrical components. Dimension measurement 1.634" L x 1.102" W (41.50mm x 28.00mm) for component details. Termination method PC Pins for electrical or mechanical linkage. Tolerance ±10% for precision in manufacturing. Peak Vce(on) at Vge 50uF for transistor parameters. Maximum DC voltage rating 450V for components.
