UPM1H221MHD6
Data Sheet
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Storage Capacity Electrical | 220uF | |
| Max Voltage Specification | 50V | |
| Accuracy Tolerance Percentage | ±20% | |
| Series Resistance Equivalent | - | |
| Expected Life at Temperature | 5000 Hrs @ 105°C | |
| Ambient Temp Range | -55°C ~ 105°C | |
| Ripple I | 670mA | |
| AC Resistance Value | 80 mOhm | |
| Pin Lead Gap | 0.197" (5.00mm) | |
| Package Size Specs | 0.492" Dia (12.50mm) | |
| Maximum Mounted Height | 0.591" (15.00mm) | |
| SMD Pad Footprint | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial, Can |
Description
Offers a capacitance level rated at 220uF to ensure circuit stability. Measures resistance at forward current 50V for LED or diode evaluation. Maximum seated height of 0.591" (15.00mm) for components mounted on the board. Set with 80 mOhm impedance to ensure signal integrity. Lead spacing 0.197" (5.00mm) for compliance with PCB design. Functions with a lifespan of 5000 Hrs @ 105°C at designated temperature. Mounting style Through Hole for structural integrity. Operating temperature -55°C ~ 105°C for thermal stability. Enclosure/case Radial, Can providing mechanical and thermal shielding. Ripple current 670mA for capacitor or inductor specifications. Dimensions 0.492" Dia (12.50mm) for mechanical or electrical components. Dimension measurement 0.492" Dia (12.50mm) for component details. Tolerance ±20% for precision in manufacturing. Peak Vce(on) at Vge 220uF for transistor parameters. Voltage specification 50V for components.
